GE TIMER – WE04X22654

This genuine GE WE04X22654 refrigerator timer is designed for use with some General Electric refrigerators. This part is the main component that tells your refrigerator when to start defrosting, and it’s responsible for turning off the compressor and fan motor at the end of the defrost cycle. It also helps to maintain accurate temperature control by measuring time and running the defrost cycle at regular intervals. This convenient timer is easy to install and provides reliable operation. We’re your #1 source for genuine OEM appliance parts. Contact us for further questions as well as any other appliance parts needs! Replacing the GE WE04X22654 Timer

1. Turn off the power to the appliance you’re working on. Disconnect the wires from the old timer and the control panel.

2. Place the new timer in the opening of the control panel and secure it with screws.

3. Find the ports on the back of the new timer that correspond to the wires from the control panel.

4. Connect the wires to the appropriate port on the timer, taking note of the correct polarity. The red wire should always connect to the port marked “L1”.

5. Secure the wires in place with the provided wire clips on the back of the timer.

6. Reconnect the power to the appliance and test your new timer.

7. Once the timer is working, use a screwdriver to adjust the timer’s settings. Make sure all settings are correct before using.

Please keep in mind, these instructions are for general guidance and should always be used in conjunction with the manufacturer’s manual, if available. Search GUD24ESSM0WW XUD27GSSM0WW XUD27ESSM0WW GUV27ESSM0WW GUD27GSSM0WW GUD27GSSJ0WW GUD27ESSM0WW GUD27ESSJ0WW GUD24GSSM0WW GUD24ESSJ0WW GTUP270EM5WW GUD27GSSJ1WW GUD27ESPM0DG GUD27GSPM0DG GUD27GSSM1WW GUD27ESSJ1WW 2661532513
